Kidney Function Analyzer – Complete and Accurate Monitoring

The Renal Function Analyzer is a new generation medical device that accurately measures three key markers of kidney health:

• Creatinine (CR)
• Urea (UR)
• Uric Acid (UA)

These parameters are essential for assessing renal function and early detection of acute or chronic renal failure . Thanks to advanced technology combining dry chemical method, enzymatic method and colorimetry , this device offers accurate and rapid results without requiring sample pretreatment .

Advanced technology for fast and reliable detection

Unlike traditional laboratory methods, which require specific conditions and a long analysis time, this analyzer uses modern technology allowing measurement in just a few minutes .

The device features a 49 mm x 37 mm LCD display , providing clear and intuitive reading of results. The measurement unit is customizable in mmol/L or mg/dL , facilitating interpretation according to medical recommendations.

It is designed for use both in medical practice and at home , and allows regular monitoring without having to travel to the laboratory.

A connected and ergonomic device

The Kidney Function Analyzer incorporates advanced connectivity options , with:

• Bluetooth for easy syncing with mobile devices and tracking apps.
• Standard USB port to connect the device to a computer to manage and store data .

With a storage capacity of 800 results , the user can follow the evolution of the measurements over time, with automatic recording of the date, time and test number .

Autonomy and reliability

The device is equipped with a rechargeable lithium battery (3.7 V, 1200 mAh) , guaranteeing:

• 30 hours of continuous use after a full charge.
• A capacity of 600 tests before needing to be recharged.
• A battery life of 1,000 charge cycles before a significant reduction in performance.

Additionally, to optimize battery life, the analyzer automatically turns off after 2 minutes of inactivity .

Conditions of use and storage

The device operates efficiently at temperatures between 2 and 40°C , with humidity up to 90% RH and a maximum altitude of 2,000 m .

To ensure reliable measurements, the analyzer must be stored in an environment of 0 to 45°C with humidity less than 90% .

Kit Contents

• Renal Function Analyzer
• USB cable for charging
• User Manual
• Built-in rechargeable lithium battery

Certifications and Compliance

In vitro diagnostic medical devices. IVD for self-test CE

Authorized EC REP representative: Lotus NL BV, Koningin Julianaplein 10, 1e Verd, 2595AA, The Hague, Netherlands
